Colour Grey
Width, mm 300
Height, mm 200
Depth, mm 150
RAL-number 7035
With mounting plate Yes
Number of doors 1
Number of locks 1
EMC-version No
With glazed door No
Floor mounting possible No
Material Steel
Wall mounting possible Yes
Degree of protection (IP) IP66
Suitable for outdoor set-up Yes
Suitable for metrical mounting Yes
Mounting plate depth-adjustable No
Tackable No
With ventilation door No
Type of surface With powder coating
Surface mounting Yes
With backside door No
Flush-mounted installation No
Enclosure type Wall-mounted
Enclosure specification With a blank door
Material Painted steel
Product type Enclosure
The accompanying goods
Drawings
Seria Name DWG STEP
Metal enclosures - "RAMblock"
