Straight metric thread connector flex. tube - box DN 23 mm, М25х1,5, polyamide, black color

Code: PAM23M25N

Straight metric thread connector flex. tube - box DN 23 mm, М25х1,5, polyamide, black color

Code: PAM23M25N
Model Plug-in
Halogen free Yes
Material Plastic
For nominal tube diameter, mm 23
Surface polished Yes
Surface brushed Yes
Two piece Yes
Diameter (nominal) 23 mm
Color Black
-5°С ... +60°С -40°С ... +105°С
Ingress Protection rating, IP from IP66 to IP68 (with optional seals)
от -25°С до +60°С from -40 ° С to + 105 ° С (short-term exposure to + 150С)
Threading M25x1,5
Product type Conduit-box coupling
ТУ 2248-012-47022248-2009 Technical specifications 2247-024-47022248-2009
3 года 3 years
15 лет 15 years
