45° elbow metric connector DN 48 mm, М50х1,5, polyamide, black color
Code:
PAL48M50N
Code:
PAL48M50N
| Colour | Black |
| Type of connection | Snap connection |
| Construction type | External thread |
| Nominal diameter, mm | 48 |
| Degree of protection (IP) | IP65 |
| Thread connection size | M50 x 1.5 |
| Model | 45°-elbow |
| Diameter (nominal) | 48 mm |
| Color | Black |
| -5°С ... +60°С | -40°С ... +105°С |
| Ingress Protection rating, IP | from IP66 to IP68 (with optional seals) |
| от -25°С до +60°С | from -40 ° С to + 105 ° С (short-term exposure to + 150С) |
| Threading | M50x1,5 |
| Product type | 45° elbow metric connector |
| ТУ 2248-012-47022248-2009 | Technical specifications 2247-024-47022248-2009 |
| 3 года | 3 years |
| 15 лет | 15 years |
