| Colour | Black |
| Model | Straight |
| Type of connection | Snap connection |
| Construction type | External thread |
| Thread type | Metric |
| Max. outer diameter hose, mm | 28.7 |
| Thread material | Polyamide (PA) |
| Nominal diameter, mm | 23 |
| Degree of protection (IP) | IP67 |
| Thread connection size | M32 x 1.5 |
| Material | Polyamide (PA) |
| от -25°С до +60°С | -40 ... +105 °C |
| -5°С ... +60°С | -40 ... +105 °C |
| Degree of protection | IP67 |
