| Width, mm | 35.2 |
| Height, mm | 90.02 |
| Depth, mm | 58.1 |
| Power consumption, VA | 130 |
| Modular version | No |
| Width in number of modular spacings | 2 |
| Voltage type of supply voltage | AC/DC |
| Power output, W | 30 |
| Output voltage stabilized | Yes |
| Type of electric connection | Screw connection |
| Rail mounting possible | Yes |
| Degree of protection (IP) | IP20 |
| 1st secondary output voltage, V | 22...29 |
| Secondary voltage adjustable | Yes |
| Rated supply voltage at AC 50 Hz, V | 90...264 |
| Rated supply voltage at AC 60 Hz, V | 90...264 |
| Rated supply voltage at DC, V | 127...370 |
| Short-circuit-proof | Yes |
| Max. output current 1, A | 1.25 |
| Nominal value output voltage 1, V | 24 |
| Nominal value output current 1, A | 1.25 |
