TMC 30x10 Cable trunking with cover, white

Colour Clear white
Width, mm 30
Height, mm 10
RAL-number 9016
Surface protection Other
Cover model Loose
Material quality PVC
Length, mm 2000
Material Plastic
Type of fastening Snapper mounting
With cable fixing clip No
With duct connector No
Useful cross section, mm² 217
Protection film No
Delivery on roll No
Transparent No
Suitable for circuit integrity No
Material PVC
Temperature of mounting, °C ­5°С ... +60°С
Width (nominal), mm 30
Ingress Protection rating, IP IP40
Average filled area, sq.mm 217
Summarized profile area (max), sq.mm 217
Temperature of operation, °C ­5°С ... +60°С
Temperature of operation, °C +60°C
Shock resistance, J 2
Climate version UHL4
Q'ty of bays 1
Voltage of disruption, V More 2500
Height (nominal), mm 10
Type Miniduct
