TMR 12x12 Cable trunking with cover, self-adhesive, white (Italy)

Code: 00308
TMR 12x12 Cable trunking with cover, self-adhesive, white (Italy)
  • To ask a question
Colour Clear white
Width, mm 12
Height, mm 12
RAL-number 9016
Surface protection Other
Cover model With film hinge
Material quality PVC
Length, mm 2000
Material Plastic
Type of fastening Self-adhesive
With cable fixing clip No
With duct connector No
Useful cross section, mm² 92
Protection film No
Delivery on roll No
Transparent No
Suitable for circuit integrity No
Material PVC
Temperature of mounting, °C ­5°С ... +60°С
Width (nominal), mm 12
Ingress Protection rating, IP IP40
Average filled area, sq.mm 92
Summarized profile area (max), sq.mm 92
Temperature of operation, °C ­5°С ... +60°С
Temperature of operation, °C +60°C
Shock resistance, J 0.5
Climate version UHL4
Q'ty of bays 1
Voltage of disruption, V More 2500
Height (nominal), mm 12
Product type Miniduct
