PDA3-45N 120 Frame-support 6 mod. 45x45 mm
Code: 00565
PDA3-45N 120 Frame-support 6 mod. 45x45 mm
Code: 00565
| Colour | White |
| Width, mm | 120 |
| Halogen free | Yes |
| Height, mm | 120 |
| Depth, mm | 26.4 |
| Number of units | 6 |
| With hinged lid | Yes |
| Surface protection | Decor |
| Built-in height, mm | 45 |
| Built-in width, mm | 45 |
| Label space/information surface | Yes |
| Material | Plastic |
| Type of fastening | Clamp mounting |
| Mounting direction | Vertical |
| Degree of protection (IP) | IP40 |
| Suitable for floor box | Yes |
| Transparent | Yes |
| Surface finishing | Glossy |
| Suitable for wall duct | Yes |
| Suitable for flush-mounted installation | Yes |
| Suitable for built-in installation | Yes |
| Number of units horizontal | 1 |
| Number of units vertical | 1 |
| Number of modules | 6 |
| Decoration | Декор по эскизу |
| Without bridge | Yes |
| Material | ABC-plastic |
| Temperature of mounting, °C | 5°С ... +60°С |
| Width (nominal), mm | 120 |
| Ingress Protection rating, IP | IP40 |
| Temperature of operation, °C | 5°С ... +60°С |
| Temperature of operation, °C | +60°C |
| Climate version | UHL4 |
| Fire protection | It is not subject to obligatory confirmation of compliance of the requirements of the Federal law №123-ФЗ 22.06.2012 |
| Product type | Supporting plate |
