Cable socket CS IP44 16A 2P 50V

Code: CS024-016-05
Code: CS024-016-05
  • To ask a question
Angle of plug Straight
Clock hour position, h 6
Cable entry Swivel
Number of poles 2
Material Plastic
IEC-amperage, A 16
Connection system Screwed terminal
Degree of protection (IP) IP44
Voltage according to EN 60309-2 40-50 V (50+60 Hz) white
GWFI +850 °С
Q'ty of poles 2P
Temperature of operation +40 °С
Material of case Ployamide
Voltage 50V
Degree of protection IP44
-5°С ... +60°С -25 °С...+40 °С
Temperature of dinamic operation -25 °С...+40 °С
Temperature of static operation -40 °С...+40 °С
Product type Cable socket
Current 16A
Color White
