Current transforme CT165 2500/5А, accuracy class-0.2, power -20ВА
Code: CT165-2500-0.2-20
Current transforme CT165 2500/5А, accuracy class-0.2, power -20ВА
Code: CT165-2500-0.2-20
Model | Single-phase current converter |
Accuracy class | 0.2 |
Calibrated | Yes |
Width opening, mm | 165 |
Height opening, mm | 60 |
Opening diameter, mm | 60 |
Number of primary inputs | 1 |
With copper rail | No |
Primary rated current, A | 2500 |
Snap mounting | No |
Secondary connection | Cable |
Secondary rated apparent power, VA | 20 |
Secondary rated current, A | 5 |
Over current limiting factor | FS 5 |
With shock protection | Yes |
Marking | CT165-2500-0.2-20 |
Series | YON CT |
Primary winding current | 2500 A |
Secondary winding current | 0.20833333333333 |
Accuracy class | 0.2 |
Hole width | 165 mm |
